Turn-Key Solvent Removal
The combo rising film wiped evaporator is setup to complete high removal of solvent and end with very low-level residual solvent in the concentrate. This setup is commonly used for concentrates that are very viscous when concentrated. The operation of the system includes process fluid pumping into the rising film evaporator where majority of the solvent is separated utilizing the large surface area. Once the concentrated oil is collected out of the rising film and into the cyclone it is then pumped into the wiped film evaporator for further reduction of solvent utilizing the mechanical action of the wiper blades.
- Best used for solvent removal (i.e. ethanol), Juice concentration, Broths, Heat sensitive products
- Feed rates of 30lbs per hour to 4000+lbs per hour
- High volume solvent removal of up to 99.9%
- Shell Tube and Plate Frame Designs for rising film
- Feed Pre-heaters and economizer to increase efficiency
- Heating is commonly completed using steam or heating oil
- National Electrical Code Hazard Environment location ratings available (etc. C1D1)
- Standard Power requirements: 208V, 3 Phase, 50-100amps
- Equipped with top-tier pumps, valves, and instruments for superior performance.
- AISI 304 stainless steel, TIG weld construction
- 304 and 316 stainless options
- High-efficiency Polyurethane insulated vessels
- Includes spray balls for easy CIP integration
- Reinforced stainless steel legs, with leveling foot pads
- Custom sizes and orientations to meet customer needs
- UL listed, 508A control panels
- Stainless steel handle Butterfly valves
- Low or high speed agitator with explosion-proof motor
Siemens automation platforms and interface
- Over twenty automated feature add-ons
- Smart device app for remote monitoring and operation
- Material handling automation
- Semi to fully automated CIP process options
- Full temperature, COL, and blending vessel automation
- SPX, FM, and E+H instrumentation and valves
- Remote access service
- UL listed, 508A control panels
